Features :

• Compact slide system with large cutting capacity
• features a fixed rail slide design that eliminates the need for rear clearance to accommodate the extension of the sliding rails. This system allows the saw to sit up against a wall or to be placed in tight work areas without compromising cutting capacity.
• 630mm wide base
• 54mm wider than the previous model C12RSH
• Sliding sub-fence
• high enough to support large work pieces for stable cutting
• 27kg in weight (without the cord)
• 2kg lighter than the previous model C12RSH
• Laser marker
• The laser casts a line over the whole cutting width
• The image at right is for illustration purposes. How it looks will depend on the environmental brightness and cut material.
• The laser line can be shifted by turning the adjuster
• Dual bevel: left/right 45
• The dual bevel feature allows cuts in both directions without the need for flipping the workpiece over. which makes the job faster.
• Positive stops
• for quick and easy miter angle setting

Specifications :

• Capacity :
• Blade Diameter : 305mm (12)
• Cross Cut 0 Degree (H x W) : 105 x 312mm (4-1/8 x 12-1/4)
• Miter Left/Right 45 Degree (H x W) : 105 x 220mm (4-1/8 x 8-5/8)
• Bevel Left 45 degree (H x W) : 68 x 312mm (2-5/8 x 12-1/4)
• Bevel Right 45 degree (H x W) : 43 x 312mm (1-11/16 x 12-1/4)
• Bevel (Left) 45 degree Miter (left) 45 degree (H x W) : 68 x 220mm (2-5/8 x 8-5/8)
• Bevel (left) 45 degree Miter (right) 31 degree (H x W) : 68 x 265mm (2-5/8 x 10-7/16)
• Bevel (Right) 45 degree Miter (right) 45 degree (H x W) : 43 x 220mm (1-11/16 x 8-5/8)
• Bevel (right) 45 degree Miter (left) 31 degree (H x W) : 43 x 265mm (1-11/16 x 10-7/16)
• Power Input : 1.520W
• No Load Speed : 4.000 rpm
• Miter Angle :
• Right : 0 - 57 degree
• Left : 0 - 45 degree
• Bevel Angle :
• Right : 0 - 45 degree
• Left : 0 - 45 degree
• Positive Miter Angle Stops : 0 . 15 . 22.5 . 31.6 . 45 degree
• Dimensions (L x W x H) : 655 x 890 x 724mm
• Weight : 27kg (without the cord)

Standard Accessories :

• Blade
• Dust Bag
• Vise Assembly
• Box Wrench
• Holder
