Features :

• RailingZX7-IGBT series introduction
• Industrial grade manual arc welding has high no-load voltage. large output power and strong environmental adaptability. Most of them use IGBT modules and high-pressure and high-power rectifier modules as power devices.After years of exploration. Railinghas established advantages in the driving and protection technology of high-power IGBT modules. The IGBT module welding machine produced by Railing.

• Large-scale power station equipment manufacturing
• Heavy-duty steel structure manufacturing enterprise
• Outdoor large-scale construction site construction

Specifications :

• Model :ZX7 500IJ
• Rated input voltage :Three-phase 38015% V

• Input frequency :50/60 Hz

• Rated input power : 25.3 KVA
• Current and voltage adjustment range :40/21.6-500/40 A/V
• 4060% duty cycle output: 500/40 A/V
• 40100% duty cycle output: 387/35.5 A/V
• Thrust adjustment : 0-100 A
• No-load voltage : 93 V
